Facilities ranging from computers, microprocessors, medical equipment to washing machines and refrigerators are based on the principle of digital electronics. Today, there is hardly any area connected with our daily lives in which the digital system has not given its knock. Actually digital technology or digital circuits are electronics that operate on digital signals. The application areas associated with digital electronics are constantly evolving. Today the field of digital electronics, which is going to touch such heights, the main reason behind this is the invention of the integrated circuit. It is the development of IC technology that made it possible to fabricate complex digital circuits such as microprocessors, memory, etc. and the digital revolution started. The invention of the microprocessor has created a stir in the technological world. Let's test your knowledge about Digital Electronics.
1. Electronic chips are a whole bunch of ____________________ put into one small area.
A. Electronic Gates
B. Electronic Resistance
C. Electronic Fibre
D. Electronic Diode
2. No matter how complex the system is, all of this work is done by these basic operations. These are basic operations is...
A. AND,OR
B. NOT
C. FLIP-FLOP
D. All of the above
3. How many values does a digital signal have?
A. Three
B. Two
C. One
D. Four
4. Which of the following is the value of the digital signal?
A. 0{low} & 1{low}
B. 0 {low} & 1 {high}
C. 0 {high} & 1{low}
D. All of the above
5. What is the output of AND gate, if all its inputs are 1?
A. Output 1
B. Output 3
C. Output 5
D. Output 7
6. Which fixed values are used for communications, storage, and math in digital electronics?
A. 0 And 2
B. 2 And 1
C. 0 And 1
D. 0 And 0
7. Which value is called HIGH in the digital language?
A. 0
B. 1
C. 3
D. 7
8. Which element is a good electrical semiconductor and is used to make most digital chips?
A. Gold
B. Copper
C. Silicon
D. All of the above
9. In most digital electronic circuits when the voltage of the circuit is positive and near the supply voltage it represents a _____________.
A. One /1
B. Three /3
C. Five /5
D. Seven /7
10. Digital electronics can also perform math using just 1's and 0's. This is called.
A. Boolean math
B. Boolean logic
C. Both of the above
D. None of these
11. If a HIGH or a 1 is input into an inverter, what is the output?
A. 1
B. 00
C. 11
D. 10
12. Who is the father of digital electronics?
A. Shannon
B. Rutherford
C. Marconi
D. Newton
